Potentiometric & Analog Linear Transducers
|
LT - Potentiometric Measuring • Absolute measurement of displacement • Small size • Potentiometric measuring • Resolution 0,01mm • Very Long Life : 100 million movements
|
|
LTM - Potentiometric Measuring • Absolute measurement of displacement • Potentiometric measuring • Resolution 0,01mm • Very Long Life : 100 million movements • Excellent Linearity %0,3
|
||
 |
LTP - Potentiometric Measuring • Absolute measurement of displacement • Twin bearing actuating rod • Mountable over backlash free pivots heads • Potentiometric measuring • Resolution 0,01mm • Very Long Life : 100 million movements • Excellent Linearity %0,3
|
 |
LTC - Potentiometric Measuring • Absolute measurement of displacement • Square body (rod diameter 6mm) • Twin bearing actuating rod • Mountable over backlash free pivots heads • Potentiometric measuring • Resolution 0,01mm • Very Long Life : 100 million movements • Excellent Linearity %0,3
|
Magnetic Linear Encoders&Sensors
 |
MLS 130 - ULTRA SMALL SIZE With Use : B Series Magnetic Tape PS 110 Profile Systems PS 200 Series Profile Systems • Very small measuring head (metal enclosure) • Wide range of available resolution up to 1 µm • Protection class IP67 • Resistant to humidity • Robust shielded aluminum • Incremental outputs A, /A, B, /B and Z Reference signal • Output signal Push-pull, TTL or RS422 line driver • 5VDC or 10...30VDC Power Supply
|
 |
MLS 110 - WITH CABLE GLAND With Use : B5 Magnetic Tape PS110 Profile Systems PS200 Series Profile Systems • Very small measuring head (metal enclosure) • Wide range of available resolution up to 1 µm • Protection class IP67 • Resistant to humidity • Incremental outputs A, /A, B, /B and Z Reference signal • Output signal Push-pull, TTL or RS422 line driver • 5VDC or 10...30VDC Power Supply
|
||
 |
MLS 110 - WITH SPIRAL GLAND With Use : B5 Magnetic Tape PS110 Profile Systems PS200 Series Profile Systems • Very small measuring head (metal enclosure) • Wide range of available resolution up to 1 µm • Protection class IP67 • Resistant to humidity • Robust shielded aluminum • Incremental outputs A, /A, B, /B and Z Reference signal • Output signal Push-pull, TTL or RS422 line driver • 5VDC or 10...30VDC Power Supply  |
 |
MLS 120 - SLIDER INTEGRATED BODY With Use : B5 Magnetic Tape PS110 Profile Systems PS200 Series Profile Systems • Very small measuring head (metal enclosure) • Socket System Sensor • Slider Integrated Body • Wide range of available resolution up to 1 µm • Protection class IP67 • Resistant to humidity • Robust shielded aluminum • Incremental outputs A, /A, B, /B and Z Reference signal • Output signal Push-pull, TTL or RS422 line driver • 5VDC or 10...30VDC Power Supply |
||
 |
MLS 210 - WITH SPIRAL GLAND With Use : PS310 Profile Systems • Metal enclosure • Protection class IP67 • Resistant to humidity • Robust shielded aluminum • Incremental outputs A, /A, B, /B and Z Reference signal • 5VDC or 10...30VDC Power Supply • Output signal Push-pull, TTL or RS422 line driver |
 |
MLS 210 - WITH SPIRAL GLAND and SLIDER JOINTS With Use : PS110 Profile Systems • Metal enclosure • Twin Sliders • Protection class IP67 • Resistant to humidity • Robust shielded aluminum • Incremental outputs A, /A, B, /B and Z Reference signal • 5VDC or 10...30VDC Power Supply • Output signal Push-pull, TTL or RS422 line driver |
||
 |
B5 Magnetic Tape - Pole Length : 5 mm With Use : MLS110 Reader Head Sensor MLS120 Reader Head Sensor MLS210 Reader Head Sensor • Easy mounting by glueing • 5 mm pole length • High accuracy Standart ±40 µm/m optional ±20 µm/m • Protection class IP67 • Resistant to humidity • Stainless steel cover strip (Upside and Downside) • Up to 100 m available • Nitrile Rubber |
|
B2 Magnetic Tape - Pole Length : 2 mm With Use : MLS110 Reader Head Sensor MLS120 Reader Head Sensor MLS210 Reader Head Sensor • Easy mounting by glueing • 2 mm pole length • High accuracy Standart ±40 µm/m optional ±20 µm/m • Protection class IP67 • Resistant to humidity • Stainless steel cover strip (Upside and Downside) • Up to 100 m available • Nitrile Rubber |
 |
ALC 77 Process Control Device || ATEK ||
Multifunctional digital pulse counter for encoders; programmable and easy to understand menu; high frequency reading rate; relay output; ALC77T (Tachometer) and ALC77B (Batch) sub-models Click for more>>
|
|||||||||
 |
ALC 94 Process Control Device || ATEK ||
Multifunctional digital pulse counter for encoders; programmable and easy to understand menu; high frequency reading rate; relay output Click for more>>
|
 |
